it’s true! The piezo buzzer is fused to the backplate, and two contacts at the top and bottom connect the buzzer and the backplate to a signal and the positive terminal of the battery, respectively. (yes technically the back of the watch and all of the button pushers are at +3V)
(original)
Replying to @josecastillo
I don’t yet have any way to make use of it, but I’ve long wanted to put one of these I²C EEPROM chips in the ’extra stuff’ area I’ve set aside in the watch. In theory it would let you get data in and out without having to take it apart and plug into USB. https://www.adafruit.com/product/4701
(original)
finally putting together a JLCPCB order with all the stuff I finished over the weekend. Also thrown in: today I recalled some prior art in Casio watch mods. The NODE Data Runner included this design for an NFC antenna in the shape of the F-91W front bezel. https://n-o-d-e.net/datarunner.html
